3. Operation
Fieldbus Communication
150
RCP6
3) Monitor menu
Click on the [Monitor] menu on the top left corner in the main window and the monitor menu list
pops up.
(Note) “Monitor” cannot be selected before reading a parameter.
• I/O data : Show the details of the host PLC and RCP6S GW data.
[Refer to 3.8.3 7) I/O data.]
• Diagnosis Information : Show the number of ERR_T and ERR_C occurrence, emergency
stops and scan time.
[Refer to 3.8.3 8) Diagnosis information.]
• Alarm List (L) : Read and show the alarm list retained in RCP6S GW.
[Refer to 3.8.3 9) Alarm list.]
3.8.2
