3. Operation
Fieldbus Communication
162
RCP6
S
3.9.3
PROFIBUS-DP
Front
Side
T
op
Side
ST
A
TUS-0
ST
A
TUS-1
{
: Illuminating, ×: OFF
, : Flashing
Name
Panel
State
Display Color
Remarks
Green (Illuminatin
g)
Online
Green (Flashing)
Online (cleared)
STATUS-1 NS
Orange (Flashing)
An error occurs. (Parameterizing error or
PROFIBUS configuration error)
Green (Illuminatin
g)
Initialization c
omplete
Green (Flashing
)
Initialization complete (
with diagnosis
event)
STATUS-0 MS
Orange (Flashing)
An error occurs. (e
xceptional error)
ME0349-4B
