IAI RCM-P6GW User Manual

2. Wiring
Fieldbus Communication
56
RCP6
S
マスタユニット
スイッチングハブ
スレーブ機器
EtherNetストレートケーブル
カテゴリ5e以上
アルミテープと編組の二重しゃ断シールド
ケーブル推奨
MSEP
EtherNet/IP仕様
4) EtherNet/IP Type
5) EtherCAT Type
6) PROFINET-IO Type
Master Unit
Switching Hub
Slave Devices
Ethernet Straight Cable, Category 5e or more
Double shielded cable braided with aluminum foil
recommended
RCP6S GW Unit
EtherNet/IP Type
Master Unit
Slave Devices
Ethernet Straight Cable
Category 5e or more
Double shielded cable braided with aluminum
foil recommended
(Note) Terminal resistance is not required
RCP6S GW
EtherCAT Type
Master Unit
Slave Devices
RCP6S GW Unit
PROFINET-IO Type
Switching Hub
Ethernet Straight Cable
Category 5 or more
Double shielded cable braided with
aluminum foil recommended
OUT
IN
IN
OUT
ME0349-4B
