MAN-045 ING
27
OVERHAUL TOOL LIST
SPECIFIC TOOLS AVAILABLE AT IAME
DESCRIPTION P.N.
• PISTON FITTING 10271
• CLUTCH LOCKING WRENCH 10270
• CLUTCH DISASSEMBLY TOOL B-55614-C
• PISTON PIN FITTING 10202
• CIRCLIP ASSEMBLY TOOL 10121
• CRANKSHAFT ASSEMBLY KIT
it includes:
- crankpin bush
10110-c
10150
• CRANKSHAFT DISASSEMBLY KIT
it includes:
- crankshaft plate
- crankshaft support
- crankpin pusher
- crankshaft insert
10100-C3
10103
10100
10107
10108
SPECIFIC TOOLS- DRAWINGS ONLY – Draw. S725/3
• ENGINE FIXING TOOL
• BEARING DISASSEMBLY TOOL
• BEARING ASSEMBLY TOOL
• CIRCLIP ASSEMBLY TOOL
STANDARD TOOLS
• ALLEN WRENCH 4mm
• ALLEN WRENCH 5mm
• HEXAGON RING WRENCH 13mm
• 12 POINT WRENCH
• 12 POINT WRENCH
10mm
13mm
• 12 POINT WRENCH 17mm
• 12 POINT WRENCH 19mm
• HEXAGON RING WRENCH 24mm
• SPARKPLUG WRENCH 20.8mm
• SCREWDRIVER WITH ROUND EDGES
• PLASTIC MALLET
• SOCKET T TYPE-DYNAMOMETRIC
13mm/10mm
- 5 MeT PRESS
