Table 1. Memory module feature codes (continued)
Supported feature codes (FC) Size
EM63 32 GB
EM64 64 GB
Memory module slot locations and population order
Memory modules must be placed in specic locations based on the number and size of memory modules
in the system. Use the following gure and table to determine where to place memory modules in the
9183-22X system.
The following gure shows the locations for memory modules in the 9183-22X system.
Figure 30. Memory module slot locations
The following table shows the order in which memory modules must be placed in the 9183-22X system.
Table 2. Memory module population order.
Memory module slot locations and number of DIMMs.
CPU 1 memory module slot locations CPU 0 memory module slot locations
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
4 DIMMs Y Y
Y Y
8 DIMMs Y Y Y Y
Y Y Y Y
Removing and replacing parts in the 9183-22X 37
