Figure 41. Replacing the fan cage assembly
6. Replace the air baffle (A) straight down into the chassis as shown in the following gure.
Ensure that the pins inside the system side walls align properly with the slots in the cover (B).
Removing and replacing parts in the 9183-22X
49
