Figure 50. Connecting the drive cables to the drive backplane
b) Lower the fan cage assembly into the system and align the fan cage assembly with the slots in the
chassis. Simultaneously rotate the two latches at (A) down as shown in the following gure until the
fan cage assembly is fully seated.
58
Power Systems: Servicing the IBM Power System IC922 (9183-22X)
