Chapter 4. IBM NeXtScale nx360 M4 compute node 89
Figure 4-12 shows the drive bay numbering. You should populate the drives in
this order.
Figure 4-12 Hard drive slot numbering
Rules for drive installation in the storage tray to ensure proper cooling:
When no a hard drive is not present in slots 0, 1, 2, and 3, a hard drive filler
must be installed to keep the proper air-flow. Slots 4, 5, and six can be empty
When a hard drive fails, it is suggested to keep the failed HDD installed until
replacing with a new hard drive.
Some drive bays can be left empty (without a filler). Only bays 0-3 require
fillers to ensure proper airflow.
Table 4-18 shows the contents of the slots and drive position.
Table 4-18 Drive bay position and fillers required according to the number of drives installed.
7x
HDDs
6x
HDDs
5x
HDDs
4x
HDDs
3x
HDDs
2x
HDDs
1x HDD No HDD
Bay 0
HDD HDD HDD HDD HDD HDD HDD Filler
Bay 1
HDD HDD HDD HDD HDD HDD Filler Filler
Bay 2
HDD HDD HDD HDD HDD Filler Filler Filler
Bay 3
HDD HDD HDD HDD Filler Filler Filler Filler
Bay 4
HDD HDD HDD Empty Empty Empty Empty Empty
Bay 5
HDD HDD Empty Empty Empty Empty Empty Empty
Bay 6
HDD Empty Empty Empty Empty Empty Empty Empty
