Chapter 4. IBM NeXtScale nx360 M4 compute node 77
Table 4-11 Maximum memory speeds (UDIMMs and LRDIMMs)
4.7 Internal disk storage options
This section provides information about the internal storage options. The RAID
controller cards and the conventional and solid-state disks (SDDs) that are
supported also are listed.
The IBM NeXtScale nx360 M4 server supports one of the following drive options:
One 3.5-inch simple-swap SATA drive
Up to two 2.5-inch simple-swap SAS or SATA HDDs or SSDs
Up to four 1.8-inch simple-swap SSDs
Rules for mixing drive types:
Mixing HDDs: Simple-swap SATA HDDs and simple-swap SAS HDDs can be
intermixed in the system, but cannot be intermixed in the same RAID array.
Mixing HDDs and SSDs: Both simple-swap SATA HDDs and simple-swap
SAS HDDs can be intermixed with SSDs in the system. SAS or SATA HDDs
cannot be configured with SSDs within the same RAID array.
Spec UDIMMs LRDIMMs
Rank Dual rank Quad rank
Part numbers 00D5012 (4GB) 46W0761 (32GB)
Rated speed 1600 MHz 1866 MHz
Rated voltage 1.35V 1.5 V
Operating voltage 1.35V or 1.5V 1.5 V
Max quantity
a
a. The maximum quantity that is supported is shown for two installed processors. When one processor
is installed, the maximum quantity that is supported is half of that shown.
88
Largest DIMM 4 GB 32 GB
Max memory capacity 32 GB 256 GB
Max memory at rated speed 32 GB 256 GB
Maximum operating speed (MHz)
1 DIMM per channel 1600 MHz 1866 MHz
