38 IBM NeXtScale System Planning and Implementation Guide
3.4 Power supplies
The IBM NeXtScale n1200 Enclosure supports up to six high-efficiency
autoranging power supplies. The standard model includes all six power supplies.
A single power supply is shown in Figure 3-5.
Figure 3-5 900 W power supply
Table 3-9 lists the ordering information for the supported power supplies.
Table 3-9 Power supplies
The power supply options have the following features:
򐂰 Supports N+N or N+1 Power Redundancy, or Non-redundant power
configurations to support higher density
򐂰 Power management controller and configured through the Fan and Power
Controller
򐂰 Integrated 2500 RPM fan
򐂰 80 PLUS Platinum certified
򐂰 Built-in overload and surge protection
Part
number
Feature
code
Description Min / Max
supported
Chassis
model
where used
00Y8569 A41T CFF 900 W Power Supply 6 / 6 A2x
00Y8652 A4MM CFF 1300W Power Supply 2 / 6 A3x, A4x
