Chapter 5. Rack planning 121
5.1.2 PDUs
There are several power distribution units that can be used with IBM NeXtScale
System. Listed in Table 5-2 are 1U rack units, which have 12 C13 outlets and are
supplied with 200 - 240 V 60 A, three-phase power or 380 - 415 V 32 A,
three-phase power.
Table 5-2 PDUs for use with IBM NeXtScale System
The switched and monitored PDU (part number 46M4005) includes an attached
line cord with IEC 609 3P+G plug. The other PDUs require a line cord, which is
listed in Table 5-3.
Table 5-3 Line cord part number
For assistance with selecting appropriate PDUs to configure, see one of the
following guides:
For North America and Japan:
http://www.ibm.com/support/techdocs/atsmastr.nsf/WebIndex/WP101526
For the International guide:
http://www.ibm.com/support/techdocs/atsmastr.nsf/WebIndex/WP101615
0U PDUs: The IBM 0U PDU should not be used in the IBM 42U 1100mm
Enterprise V2 Dynamic Rack with the NeXtScale n1200 Enclosure because
there is inadequate clearance between the rear of the chassis and the PDU.
Part number Description
Switched and Monitored PDU
46M4005 IBM 1U 12 C13 Switched and Monitored 60 A 3-Phase PDU
46M4004 IBM 1U 12 C13 Switched and Monitored PDU without line cord
Monitored PDU
39M2816 IBM DPI C13 Enterprise PDU without line cord
Basic PDU
39Y8941 IBM Enterprise C13 PDU
Part number Description
40K9611 32 A 380-415V IEC 309 3P+N+G (non-US) Line Cord
