98 IBM NeXtScale System Planning and Implementation Guide

4.12.2 Single-slot riser card

Additional PCIe cards can be mounted by using a 1U single-slot riser cage. The

1U riser cage provides one PCIe 3.0 x16 slot full-height/half-length. The x16 slot

that is provided by the riser (see Table 4-24) can be used to connect a

ServeRAID controller or any of the other adapters that are listed in Table 4-25 on

page 99 and Table 4-27 on page 101.

Table 4-24 PCIe raiser cage option

InfiniBand Mezzanine Card

00AM476 A4WA IBM Dual Port FDR10/QDR embedded adapter for nx360 M4

00D4143 A36R IBM Dual Port FDR Embedded Adapter

FCoE / iSCSI upgrades - IBM Features on Demand

90Y5179 A2TF QLogic Embedded VFA FCoE/iSCSI License for IBM System x (FoD)

(for 90Y6454)

Part

number

Feature

code

Description

PCIe Native Expansion Tray: If the PCIe Native Expansion Tray is selected,

then this single-slot riser cage is not used. Instead the tray includes a two-slot

riser card. See 4.9, “IBM NeXtScale PCIe Native Expansion Tray” on page 90

Part number Feature

code

Description Maximum

supported

46W2744 A41R nx360 M4 PCIe riser 1
