Chapter 4. IBM NeXtScale nx360 M4 compute node 103
4.14 Local server management
The nx360 M4 provides local console access through the keyboard, video, and
mouse (KVM) connector on the front of the server. A console breakout cable is
used with this connector. The cable is shown in Figure 4-19.
Figure 4-19 Console breakout cable
One console breakout cable is shipped with the IBM NeXtScale n1200
Enclosure. Other cables can be ordered. The ordering part number is listed in
Table 4- 29.
Table 4-29 Console breakout cable
Part
number
Feature
code
Description Maximum
supported
00Y8366 A4AK Console breakout cable (KVM Dongle cable) 1
Same cable as Flex System: This is the same cable that is used with IBM
Flex System, but it has a different part number because of the included
materials.
