60 IBM NeXtScale System Planning and Implementation Guide
4.10, “GPU and coprocessor adapters” on page 92
4.11, “Embedded 1 Gb Ethernet controller” on page 96
4.12, “PCI Express I/O adapters” on page 97
4.13, “Integrated virtualization” on page 102
4.14, “Local server management” on page 103
4.15, “Remote server management” on page 105
4.16, “External disk storage expansion” on page 107
4.17, “Physical specifications” on page 110
4.18, “Operating systems support” on page 112
4.1 Overview
The IBM NeXtScale nx360 M4 compute node contains only the essential
components in the base architecture to provide a cost-optimized platform. The
nx360 M4 compute node provides a dense, flexible solution with a low total cost
of ownership.
Figure 4-1 IBM NeXtScale nx360 M4 compute node
The nx360 M4 compute nodes fit into the IBM NeXtScale n1200 Enclosure that
provides common power and cooling resources. As shown in Figure 4-1, the
nx360 M4 compute node can support the following components:
One or two Intel Xeon E5-2600 v2 series processors.
Up to eight DIMMs of registered DDR3 ECC memory and operating up to
1866 MHz, which provides a total memory capacity of up to 128 GB.
One on-board 1 Gb Ethernet port and one on-board 1 Gb
Ethernet/management port.
