Chapter 4. IBM NeXtScale nx360 M4 compute node 99
Figure 4-17 shows the 1U riser cage.
Figure 4-17 1U single slot PCIe riser cage
4.12.3 Network adapters
Table 4-25 lists other supported network adapters in the standard full-height
half-length PCIe slot.
Table 4-25 Network adapters
PCIe riser
PCIe 3.0 x16 slot (full height,
half-length adapters)
Part number Feature code Description
40 Gb Ethernet
00D9550 A3PN Mellanox ConnectX-3 FDR VPI IB/E Adapter for IBM System x
10 Gb Ethernet
94Y5180 A4Z6 Broadcom NetXtreme Dual Port 10GbE SFP+ Adapter for IBM System x
49Y7910 A18Y Broadcom NetXtreme II Dual Port 10GBaseT Adapter for IBM System x
00D8540 A4XH Emulex Dual Port 10GbE SFP+ VFA IIIr for IBM System x
49Y7960 A2EC Intel X520 Dual Port 10GbE SFP+ Adapter for IBM System x
00D9690 A3PM Mellanox ConnectX-3 10 GbE Adapter for IBM System x
42C1800 5751 QLogic 10Gb CNA for IBM System x
47C9952 A47H Solarflare SFN5162F 2x10GbE SFP+ Performant Adapter for IBM
System x
47C9960 A47J Solarflare SFN6122F 2x10GbE SFP+ Onload Adapter for IBM System x
