146 IBM NeXtScale System Planning and Implementation Guide
Table 5-14 Fibre Channel switch part numbers
For more information about IBM Fibre Channel switches, see this website:
http://www.ibm.com/systems/networking/switches/san/
5.7 Rack-level networking: Sample configurations
In this section, we describe the following sample configurations that use
NeXtScale systems:
򐂰 InfiniBand non-blocking
򐂰 InfiniBand 50% blocking
򐂰 10 Gb Ethernet configuration with one port per node
򐂰 10 Gb Ethernet configuration with two ports per node
The location of the chassis and the switches within the rack are shown in a way
that optimizes the cabling of the solution. The chassis and switches are
color-coded to indicate which InfiniBand or Ethernet switches support which
chassis.
16 Gb Fibre Channel switches
Part number Description
2498F24 IBM System Storage® SAN24B-5
2498F48 IBM System Storage SAN48B-5
2498F96 IBM System Storage SAN96B-5
8 Gb Fibre Channel switches
249824E IBM System Storage SAN24B-4 Express
241724C Cisco MDS 9124 Express
2417C48 Cisco MDS 9148 for IBM System Storage
2498B80 IBM System Storage SAN80B-4
Management network: Management networking is the same for all
configurations. For more information, see 5.7.5, “Management network” on
page 151.
