IBM NeXtScale System User Manual

100 IBM NeXtScale System Planning and Implementation Guide
More network adapters are offered as part of the IBM Intelligent Cluster program,
as listed in Table 4-26.
Table 4-26 Network adapters that are offered as part of the Intelligent Cluster program
47C9977 A522 Solarflare SFN7122F 2x10GbE SFP+ Flareon Ultra for IBM System x
Gigabit Ethernet
90Y9352 A2V3 Broadcom NetXtreme I Quad Port GbE Adapter for IBM System x
90Y9370 A2V4 Broadcom NetXtreme I Dual Port GbE Adapter for IBM System x
49Y4230 5767 Intel Ethernet Dual Port Server Adapter I340-T2 for IBM System x
49Y4240 5768 Intel Ethernet Quad Port Server Adapter I340-T4 for IBM System x
InfiniBand
00D9550 A3PN Mellanox ConnectX-3 FDR VPI IB/E Adapter for IBM System x
Part number Feature code Description
Part number Feature code Description
40 Gb Ethernet
46W0620 A4H5 Chelsio T580-LP-CR Dual-port (QSFP+) 40GbE PCI-E 3.0 Adapter
95Y3459 A2F8 Mellanox ConnectX-3 EN Dual-port QSFP+ 40GbE Adapter
10 Gb Ethernet
00AE047 A4K1 Mellanox ConnectX-3 EN Single-port SFP+ 10GbE Adapter
00W0053 A2ZQ Mellanox ConnectX-3 EN Dual-port SFP+ 10GbE Adapter
00Y7006 A3G7 Brocade 1860 Dual-port SFP+ 10GbE Fabric Adapter
00Y7026 A3GE Brocade 1860 Single-port SFP+ 10GbE Fabric Adapter
46W0609 A4H3 Chelsio T520-LL-CR Dual-port (SFP+) 10GbE PCI-E 3.0 Adapter
46W0615 A4H4 Chelsio T540-CR Quad-port (SFP+) 10GbE PCI-E 3.0 Adapter
InfiniBand
00W0037 A2YE Mellanox ConnectX-3 VPI Single-port QSFP FDR IB HCA
00W0041 A2YF Mellanox ConnectX-3 VPI Dual-port QSFP FDR IB HCA
46W0571 A44E Mellanox Connect-IB Dual-port QSFP FDR IB PCI-E 3.0 x16 HCA
59Y1888 5763 Intel QLE7340 single-port 4X QDR IB x8 PCI-E 2.0 HCA
