Chapter 4. IBM NeXtScale nx360 M4 compute node 109
Table 4-33 External SAS cables for external storage expansion enclosures
Table 4-34 lists the drives that are supported by EXP2512 external expansion
enclosures.
Table 4-34 Drive options for EXP2512 external expansion enclosures
Table 4-35 lists the hard disk drives that are supported by EXP2524 external
expansion enclosures.
Table 4-35 Drive options for EXP2524 external expansion enclosures
Part
number
Description Maximum supported
per one enclosure
39R6531 IBM 3 m SAS Cable 1
39R6529 IBM 1 m SAS Cable 1
Part
number
Description Maximum supported
per one enclosure
3.5" NL SAS HS HDDs
49Y1903 1TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
49Y1902 2TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
90Y8720 3TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
46W0975 4TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
3.5" SAS HS HDDs
49Y1899 300GB 15,000 rpm 6Gb SAS 3.5" HDD 12
49Y1900 450GB 15,000 rpm 6Gb SAS 3.5" HDD 12
49Y1901 600GB 15,000 rpm 6Gb SAS 3.5" HDD 12
Part
number
Description Maximum supported
per one enclosure
2.5" NL SAS HS HDDs
49Y1898 500GB 7,200 rpm 6Gb SAS NL 2.5" HDD 24
81Y9952 1TB 7,200 rpm 6Gb SAS NL 2.5" HDD 24
2.5" SAS HS HDDs
49Y1896 146GB 15,000 rpm 6Gb SAS 2.5" HDD 24
