Chapter 5. Rack planning
129
Six 1U v
er
tical mounting brac
kets in the rear post fla
nges, which can be
used
f
or pow
er distributio
n units, s
witches, or other 1U de
vices, as shown in
Figure
5-8.
Figure 5-8 1
U P
ower distribution unit mounted in
1U pock
et on flange of
rear post
M6 clip nuts
Cabl
e
openings
146
148
