152 IBM NeXtScale System Planning and Implementation Guide
Each chassis has one management port that plugs to the Fan and Power
Controller, which is at the rear of the chassis. Each PDU can also have a
management port.
Note: The management cables that connect to devices at the rear of the
chassis should be routed to the front of the chassis via the cable channels.
