Chapter 3. IBM NeXtScale n1200 Enclo
sure
25
Figure 3-2 IBM NeXtScale n1200 Enclosure componen
ts
The IBM NeXtScale n1200 Enclosure includ
es the f
ollowin
g components:
Up to 12 compute nodes
Six power supplies each separately pow
ered
A total of 10 fan modules in
two cooling zones
One F
an and P
ower Controller
Shipping
bracket kit
Midplane
T
op cover
Fan modules
Fan and
Power
Controller
Power
supplies
Rail kit
Node filler
Lift handles
