30 IBM NeXtScale System Planning and Implementation Guide
򐂰 UEFI settings
To size for a specific configuration, you can use the IBM Power Configurator that
is available at this website:
http://ibm.com/systems/bladecenter/resources/powerconfig.html
The following show the number of nodes that can be operated with no
performance compromise within the chassis depending on the power policy
required. The tables are as follows:
򐂰 1300 W power supplies:
– 200-240V AC input, no GPU Trays: Table 3-2
– 200-240V AC input, GPU Trays with 130 W GPUs: Table 3-3 on page 32
– 200-240V AC input, GPU Trays with 225 W GPUs: Table 3-4 on page 33
– 200-240V AC input, GPU Trays with 235 W GPUs: Table 3-5 on page 34
– 200-240V AC input, GPU Trays with 300 W GPUs: Table 3-6 on page 35
򐂰 900 W power supplies:
– 200-240V AC input, no GPU Trays: Table 3-7 on page 36
– 100-127V AC input, no GPU Trays: Table 3-8 on page 37
Table 3-2 shows the quantity supported of compute nodes with six 1300 W power
supplies installed in the chassis.
Table 3-2 Number of compute nodes supported (high-line AC Input, with 6 x 1300 W PSUs)
Power Configurator: Use the IBM Power Configurator to determine an
accurate power model for your configuration.
http://ibm.com/systems/bladecenter/resources/powerconfig.html
Compute nodes Power policy - 6 x 1300W power supplies
CPU TDP
Number of
CPUs
Non-redundant
or N+1 with OVS
a
N+1 N+N
N+N
with OVS
a
High line AC input (200-240 V)
50 W 1
12 12 12 12
2
12 12 12 12
60 W 1
12 12 12 12
2
12 12 12 12
70 W 1
12 12 12 12
2
12 12 12 12
