62 IBM NeXtScale System Planning and Implementation Guide
Figure 4-3 shows the locations of key components inside the server.
Figure 4-3 Inside view of the IBM NeXtScale nx360 M4
CPU 2 and
four DIMMs
CPU 1 and
four DIMMs
Mezz card
connector
PCIe 3.0
riser slot 1
PCIe 3.0
riser slot 2
(PCIe Tray only)
USB hypervisor
socket
Midplane
connector
KVM and
Ethernet
Drive bay(s)
SATA port
and cable
