Replaceable components are of three types:
v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your responsibility. If IBM
installs a Tier 1 CRU at your request, you will be charged for the installation.
v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or request IBM to install it, at
no additional charge, under the type of warranty service that is designated for your blade server.
v Field replaceable unit (FRU): FRUs must be installed only by trained service technicians.
For information about the terms of the warranty and getting service and assistance, see the information
center or the Warranty and Support Information document on the IBM BladeCenter Documentation CD.
Table 36. Parts listing, Type 8406
Index Description
CRU part number
FRU part
number
Failing
function
code (FFC)
(Tier 1) (Tier 2)
Base system-board and chassis assembly, with 1
POWER7 four core microprocessor
74Y1810
Various,
see
“Failing
function
codes 151
through
2E33” on
page 181
1 Cover 46C7341
2
4x InfiniBand DDR Expansion Card (CFFh) for
BladeCenter (option)
49Y9976
2
Combo 4Gb Fibre Channel Expansion Card, 1 GB
Ethernet Card, (CFFh/PCIe) (option)
39Y9304
2
QLogic 8 Gb Fibre Channel and 1 Gb Ethernet
expansion card (CFFh/PCIe) (option)
44X1943 2E12
2
QLogic 2 port 10 GB Ethernet FCoE Expansion Card,
(CFFh/PCIe) (option)
42C1832
3 3Gb SAS Passthrough Expansion Card (CIOv) (option) 46C4069 2506
3
QLogic 4Gb Fibre Channel 1Xe PCI-Express Expansion
Card (CIOv) (option)
49Y4237 2E13
3
QLogic 8Gb Fibre Channel 1Xe PCI-Express Expansion
Card (CIOv) (option)
44X1948 2E14
3
Emulex 8Gb Fibre Channel Expansion Card (CIOv)
(option)
46M6138 2607
4 Bezel assembly with control panel 46K5760
4 OEM Bezel assembly with control panel 46K4683
5 DIMM filler 60H2962
6
Memory, 4GB DDR3, 1066MHz VLP RDIMM (option)
77P8691
219
2C6
6
Memory, 8GB DDR3, 800MHz VLP RDIMM (option)
77P8692
219
2C6
7 Management card 74Y1978
8 Tray, SAS hard disk drive 31R2239
9 300GB 10K RPM SFF SAS HDD and screws (4) (option) 42D0628
9 600GB 10K RPM SFF SAS HDD and screws(4) (option) 49Y2023
