Table 15. Enclosure weight as FRUs are installed (continued)
Enclosure assembly Approximate weight
FRUs installed FRUs not installed kg lb
Note: The following FRUs
are installed when the
enclosure is initially
shipped.
• Enclosure (01LJ607 or
01LJ112)
• Secondary expansion
modules
• PSUs
• Expansion canisters
• Fan modules
• Fan interface board
• Display assembly
• Cover
• Fascia (1U and 4U)
• Drives
61.5 135.4
• Enclosure (01LJ607 or
01LJ112)
• Secondary expansion
modules
• Fascia (1U and 4U)
• PSUs
• Expansion canisters
• Fan modules
• Fan interface boards
• 92 2.5-inch tier 1 flash
drives
• Cover
78.6 173.3
• Enclosure (01LJ607 or
01LJ112)
• Secondary expansion
modules
• Fascia
• PSUs
• Expansion canisters
• Fan modules
• Fan interface board
• 92 2.5-inch hard disk
drives
• Cover
86 189.6
Chapter 4. Installing an optional 5U SAS expansion enclosure 49
