Fibre Channel specifications
Table 9. Fibre Channel specifications
System component Description
Fibre Channel ports Twenty four 2/4/8/16 Gbps ports
compatible with short wavelength (SWL),
long wavelength (LWL), and extended long
wavelength (ELWL) SFP+ transceivers
(available wavelength options vary for 8 and
16 Gbps SFPs) and capable of
autonegotiating to maximum link speed
ANSI Fibre Channel protocol Fibre Channel Physical and Signaling
Interface standard (FC-PH)
Modes of operation Fibre Channel Class 2 and Class 3
Fabric initialization Complies with FC-SW-3 Rev. 6.6
FCIP (Fibre Channel over IP) Complies with FC-IP 2.3 of FCA profile
Ethernet specifications
Table 10. Ethernet specifications
System component Description
SFP GbE ports Sixteen 1/10 GE and two 40 GE
optical/copper ports compatible with ultra
short reach (USR), short reach (SR), long
reach (LR), and copper SFP/SFP+
transceivers (available reach options vary
from 1GbE, 10GbE and 40GbE)
Ethernet management port One with 10/100/1000 Mbps
auto-negotiating capability
Connectors
Table 11. Connector types
Component Description
Serial cable One IEEE-compliant RJ-45 serial cable 10-ft
(approximately 3 m) long
RJ-45 to DB9 adaptor One
RJ-45 connector One IEEE-compliant on the port side of the
Extension Switch for use with a serial
console and 10/100 Mbps Ethernet +
LED specifications
Table 12. LED types
Component Description
Switch status and management LEDs
One power
One system
One per FC port
One per Ethernet port
Two for Ethernet management port
50 SAN42B-R Installation, Service, and User Guide
