IBM Storwize V5000E User Manual

Table 12. Enclosure physical characteristics (continued)
Enclosure type Model Height Width Depth Maximum weight
Drive ready
(without
drives)
Fully
congured
(with drives)
Expansion
enclosure (12
LFF drive slots)
Storwize
V5000E
( 2072-12F )
Storwize
V5000E (2072-
E12)
8.7 cm (3.4 in) 48.3 cm (19.0
in)
55.6 cm (21.9
in)
16.4 kg (36.1
lb)
26.7 kg (58.9
lb)
Expansion
enclosure (24
SFF drive slots)
Storwize
V5000E
2072-24F )
Storwize
V5000E (2072-
E24)
8.7 cm (3.4 in) 48.3 cm (19.0
in)
55.6 cm (21.9
in)
16.7 kg (36.8
lb)
25.0 kg (55.1
lb)
Expansion
enclosure (92
drive slots)
Storwize
V5000E
( 2072-92F )
Storwize
V5000E (2072-
E92)
222.2 mm
(8.75 in.)
483 mm (19.0
in.)
968 mm (38.1
in.)
67 kg (147.7 lb) 135 kg (297 lb)
Attention: To avoid potential equipment damage during transport and subsequent loss of data,
see Procedure: Transporting a 5U 92-drive expansion enclosure. The procedure describes what to
do for the following situations.
• When you are powering off a 92F, 92G, or an A9F 5U expansion enclosure because you intend to
transport it to another location
• When you intend to move a rack that contains a 92F, 92G, or an A9F 5U expansion enclosure
The procedure describes how to remove each drive from the 5U enclosure and transport the
enclosure. Removing the drives prevents damage to the drives and makes the lighter enclosure
easier to move.
Warning: 2072-92F or 2072-E92 (5U) expansion enclosure models need 968 mm from the rack
front post to the back of the cable management arm (CMA). There are racks that will not provide
sufcient space to close the rear door. In addition, allow 905 mm from the front post to the back
of the enclosure. To allow space for the power cables, provide 60 - 70 mm from the back of the
enclosure.
Figure 3 on page 10 shows the rack space requirements for the 5U models.
Chapter 2. Environmental requirements
9
