Other expansion enclosure parts
Table 34 on page 64 summarizes the part numbers and feature codes for other parts. The values are the
same for all systems that support the 5U expansion enclosure.
Table 34. Other expansion enclosure parts
FRU Part Number Description Comments
00AR317 3 m 12 Gb SAS Cable (mSAS HD)
00AR439 6 m 12 Gb SAS Cable (mSAS HD)
01LJ114 Rail kit
01LJ116 Front fascia (4U front cover)
01LJ118 Display panel assembly
01LJ120 PSU fascia (1U cover) The fascia must be removed to
access the power supply units.
01LJ122 Power supply unit (PSU) The expansion enclosure contains 2
PSUs. Each PSU requires a
C19/C20 power cord.
01LJ124 (for use with enclosure
FRU P/N 01LJ112)
01LJ860 (for use with enclosure
FRU P/N 01LJ607
Secondary expansion module The expansion enclosure supports
two-secondary expansion modules.
CAUTION: Use caution
when you are removing or
replacing a secondary
expansion module from an
enclosure with FRU part
number 01LJ112. Avoid
contact with the connectors
on the main board.
01LJ126 Fan module The expansion enclosure contains
four fan modules.
01LJ128 Expansion canister
01LJ130 Cable management arms (CMA) The part contains the upper and
lower CMA.
01LJ132 Top cover
01LJ134 Fan interface board
01LJ607 Enclosure
Note: Replaces enclosure FRU P/N
01LJ112.
Includes the drive board, signal
interconnect board, and internal
power cables, in an otherwise
empty enclosure.
39M5388 16A power cord C19/C20 2 m
Connecting 2U expansion enclosures to the control enclosure
If you have 2U expansion enclosures in the rack, you must connect them to the control enclosure.
About this task
This task applies if you are installing one or more expansion enclosures.
Table 35 on page 65 shows the number of SAS chains and enclosures that are supported by the system.
64
IBM Storwize V5000E : Storwize V5000E Quick Installation Guide
