IBM SurePOS 700 Series Hardware Service Guide

Asm–
Index
Part
Number Units
Description
Top cover assemblies (without rear door):
1–1 45T9214 1 Narrow top cover assembly; storm (light) gray
–1 45T9215 1 Narrow top cover assembly; iron (dark) gray
–1 45T9216 1 Narrow top cover assembly; litho gray
–2 45T9217 1 Wide top cover assembly; storm (light) gray
–2 45T9218 1 Wide top cover assembly; iron (dark) gray
–2 45T9219 1 Wide top cover assembly; litho gray
Rear door assemblies:
–3 45T9220 1 Narrow standard rear door; storm (light) gray
–3 45T9221 1 Narrow standard rear door; iron (dark) gray
–3 45T9222 1 Narrow standard rear door; litho gray
–4 44T5697 1 Narrow cable arm rear door; storm (light) gray
–4 44T5699 1 Narrow cable arm rear door; iron (dark) gray
–4 45T9001 1 Narrow cable arm rear door; litho gray
–5 45T9223 1 Wide standard rear door; storm (light) gray
–5 45T9224 1 Wide standard rear door; iron (dark) gray
–5 45T9225 1 Wide standard rear door; litho gray
–6 73Y1976 1 Wide cable arm rear door; storm (light) gray
–6 73Y1978 1 Wide cable arm rear door; iron (dark) gray
–6 73Y1980 1 Wide cable arm rear door; litho gray
Front bezel assemblies (includes front door, USB door, headphone jack
plug, and uninterruptible power supply blank if wide):
–7 44T5216 1 Narrow front bezel assembly; storm (light) gray
–7 44T5218 1 Narrow front bezel assembly; iron (dark) gray
–7 44T5220 1 Narrow front bezel assembly; litho gray
– 44T5228 1 Narrow coverless front bezel assembly; storm (light) gray
– 44T5230 1 Narrow coverless front bezel assembly; iron (dark) gray
– 44T5232 1 Narrow coverless front bezel assembly; litho gray
–8 44T5222 1 Wide front bezel assembly; storm (light) gray
–8 44T5224 1 Wide front bezel assembly; iron (dark) gray
–8 44T5226 1 Wide front bezel assembly; litho gray
– 44T5234 1 Wide coverless front bezel assembly; storm (light) gray
– 44T5236 1 Wide coverless front bezel assembly; iron (dark) gray
– 44T5238 1 Wide coverless front bezel assembly; litho gray
–9 73Y1310 1 Cable arm assembly
–10 46N1998 1 Power Supply
–10 46N1996 1 Power Supply
–11 45T9031 1 Lock assembly (includes barrel, bracket, lock cam, and screws)
– 47J5575 1 Lock plug
–12 45T9027 1 Drive bay door assembly (includes drive bay door, drive bay door pin, and drive bay
door pull handle)
–13 45T9035 1 DASD cage assembly (includes metal DASD cage and DASD riser card) for IDE
CDROM and DVD for Models 723, 743, and 783
–13 73Y0014 1 DASD cage assembly (includes metal DASD cage and DASD riser card) for SATA
CDROM and DVD for Models 723, 743, and 783
–14 45T9038 1 HDD, 80 GB, SATA attached assembly (includes drive, rails, and screws)
–14 45T9041 1 HDD, 160 GB, SATA attached assembly (includes drive, rails, and screws)
Assembly 1: (continued)
Appendix A. Parts catalog 79
