IBM SurePOS 700 Series Hardware Service Guide

Asm–
Index
Part
Number Units
Description
Top cover assemblies (without rear door):
–14 73Y0013 1 HDD, 250 GB, SATA attached assembly (includes drive, rails, and screws)
–14 99Y1403 1 SSD, 64 GB, SATA attached assembly (includes drive, rails, and screws)
–15 45T9039 1 CD-RW assembly (includes CD-RW drive, bracket, and screws) IDE
–15 45T9040 1 DVD-RW assembly (includes DVD-RW drive, bracket, and screws) IDE
–15 45T9043 1 Floppy disk drive (FDD) assembly (includes FDD, bracket, and screws)
– 73Y0010 1 CD-RW-SATA
– 73Y0011 1 DVD-RW-SATA
– 45T9044 1 Optical drive blanking shield
– 46N2139 1 Filler Panel (for use when no DASD cage is installed)
– 06P5223 1 External FDD
–17 45T9048 1 PCI/PCI Express riser assembly (includes spline and riser card)
– 45T9056 1 PCI/PCI Express riser card
–17 45T9054 1 Dual PCI riser assembly (includes spline and riser card)
– 45T9057 1 Dual PCI riser card
– 45P6222 1 Riser card battery
– 45T9059 1 Riser bracket
– 46N1992 1 I/O module (3 RS-485, 3 USB,S3)
–18 45T9083 1 I/O module (top, 5 USB)
–18 45T9085 1 I/O module (top, RS-232)
–18 45T9082 1 I/O module (RS-232; RPQ only)
–18 45T9084 1 I/O module (top, RS-485)
–18 46N5020 1 I/O module (top RS-485) 24 V
–18 47J5582 1 I/O module (3 9–pin RS-232)
–18 47J5583 1 I/O module (1 9–pin RS-232, 3 USB, 1 cash drawer)
– 45T9045 1 I/O module blank
– 45T9058 1 SurePort door
– 46N1981 1 System board; Models 723 and E23 (includes processor, heatsink, and system board
tray for S3)
–19 46N1983 1 System board; Models 743, C43, E43, 783, and E83 (includes system board tray for
S3)
– 45P6222 1 System board battery
– 73Y0001 1 System board Models 784, C84, and E84
–20 45T9055 1 Processor, Intel Celeron 440 2.0 GHz, Models 743, C43, and E43
–20 45T9049 1 Processor; Intel Core 2 Duo E4300 1.8 GHz, Models 783 and E83
–21 45T9067 1 Heatsink assembly with fan, Models 743, C43, E43, 783, E83, 784, C84, and E84.
– 80Y6747 Heatsink, thermal pad (5 pack) (used with 45T9067)
–21 93Y0050 1 Heatsink assembly with fan, Models 743, C43, E43, 783, E83, 784, C84, and E84.
–22 45T9071 1 Processor fan, Models 743, C43, E43, 783, E83, 784, C84, and E84 (45T9067 -
used only).
– 45T9069 1 Processor fan, Models 723 and E23
– 45T9985 1 Memory, 256 MB DDR2, Models 723 and E23
– 45T9986 1 Memory, 512 MB DDR2, Models 723 and E23
– 45T9987 1 Memory, 1 GB DDR2, Models 723 and E23
– 45T9066 1 Memory, 512 MB DDR2, Models 743, C43, E43, 783, and E83
– 45T9079 1 Memory, 1 GB DDR2, Models 743, C43, E43, 783, and E83
Assembly 1: (continued)
80
SurePOS 700-723/743/783/784 Hardware Service Guide
