IBM SurePOS 700 Series Hardware Service Guide

Asm–
Index
Part
Number Units
Description
Top cover assemblies (without rear door):
– 45T9080 1 Memory, 2 GB DDR2, Models 743, C43, E43, 783, and E83
–23 1 Pullout tray
–24 45T9016 1 Unit frame
–25 44T5249 1 Wide uninterruptible power supply housing
– 45T9339 1 Wide uninterruptible power supply housing without feet
– 45T9997 1 PCI Express Video Adapter, Models 723, E23
– 23K8110 1 Uninterruptible power supply housing closeout
–26 42M5861 1 Low voltage uninterruptible power supply (optional; wide systems only)
–26 42M5860 1 High voltage uninterruptible power supply (optional; wide systems only)
– 73Y0008 1 1 GB DDB Models 784, E84, C84
– 73Y0009 1 2 GB DDB Models 784, E84, C84
– 73Y0166 1 Intel Processor - E5300, Models 784, E84, C84
– 73Y0167 1 Intel Processor - E7400, Models 784, E84, C84
– 80Y0824 1 Uninterruptible power supply battery
2
–27 45T9018 1 Switch/LED card. Use for Models 723,743,783,E23,E43,E83,C43 system board Rev
1.0
–27 46N1994 1 Switch/LED card. Use for Models 723,743,783,E23,E43,E83,C43 system board Rev
1.1 and higher and for Models 784, E84 and C84
–28 45T9022 1 Front USB/Audio card
– 45T9046 1 Front USB/Audio blanking shield
–29 45T9086 1 Uninterruptible power supply cover; storm (light) gray
–29 45T9088 1 Uninterruptible power supply cover; iron (dark) gray
–29 45T9090 1 Uninterruptible power supply cover; litho gray
– 45T9092 1 Miscellaneous hardware kit
3
Options:
– 42C0060 1 Keyboard, PS/2 preferred
– 39X8908 1 Modular flash drive
– 41A3542 1 Vertical stand, storm (light) gray
– 41A3543 1 Vertical stand, iron (dark) gray
– 41A3544 1 Vertical stand, litho gray
Cables:
– 45T9025 1 Cable, front USB
– 45T9020 1 Cable, switch/LED card
– 44T5667 1 Cable, serial port (black connectors)
– 44T5669 1 Cable, serial port (blue connectors)
– 45T9436 1 Cable, Ethernet, CAT6
– 42M5651 1 Cable, cash drawer adapter (SDL to RJ11)
– 39M5380 1 Cable, uninterruptible power supply power (500 mm)
– 42M5862 1 Cable, uninterruptible power supply communications (310 mm)
2. SurePOS 700 uninterruptible power supply batteries are a consumable item and, as such, you are responsible for replacing them.
IBM warrants the original uninterruptible power supply battery for 90 days from the ship date to the customer or distributor. In the
United States and Canada, you can purchase replacement batteries (P/N 23K8052) by calling 1-800-IBM-CALL (1-800-426-2225).
If you are located outside of the United States and Canada, contact your IBM representative.
3. Includes blue tip, keylock cam screw, CD-ROM screw, M3 screws, M4 flat-head screws, 6-32 screws, serial port standoff, main
feet, center foot, center foot pin, PCI blank, cover plug, lock plug, and labels.
Assembly 1: (continued)
Appendix A. Parts catalog 81
