IBM System x3650 M4 Type 7915 User Manual

Tape drive
power cables
SATA tape
drive signal
cable
6. Slide the tape-drive assembly most of the way into the tape-drive bay.
7. Connect the SAS signal cable and the power cable to the back of the tape
drive.
Attention: Make sure that all the cables are positioned underneath the
tape-drive assembly before you insert the assembly in the tape-drive bay.
Otherwise, the cables might be damaged.
8. Slide the tape-drive assembly the rest of the way into the tape-drive bay.
9. Push the latch to the closed (locked) position.
If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 135.
100 System x3650 M4 Type 7915: Installation and User’s Guide
