13
5.MinimumDeadband(1°Fto9°F)(1°Cto5°C)
SettheminimumseparationbetweenheatsetpointandcoolsetpointinAutoChangeoverMode.
Pressthe
or tosetdeadbandvalue.
Press
toadvancetothenextscreen.
CONFIG
7.AuxiliaryDelayON(0-60minutes)
Setthedelaytimeinminutesforauxiliaryheattobelockedoutafteracallforsecondstage.This
extrasavingsfeatureisusedtotemporarilylockoutauxiliaryheatdevices,allowingjustheat
pumptotrytosatisfyheatcall.
Pressthe
or toselect.Press toadvancetothenextscreen.
CONFIG
HEAT
6.HeatSource:Therearesixheatsourcesettings:
WARNING! : Incorrectsettingscandamagesystemand/orcausepotentiallydangerousconditions.Usethecode
describedinCongurationandThermostatLock.
Non-HeatPump
CONFIG
Electric
CONFIG
Gas
HeatPump
CONFIG
HeatPumpwith
2compressors
andHeatActive
ReversingValve
CONFIG
HeatPumpwith
2compressors
andCoolActive
ReversingValve
CONFIG
HeatPumpwith
1compressor
andHeatActive
ReversingValve
CONFIG
HeatPumpwith
1compressor
andCoolActive
ReversingValve
