ICM Controls I3 1010HR - Humidity Output Chart

9
* Gnotonfor
gas/oilsystems
2020HR Output Chart
1
ST
Cool 2
ND
Cool 1
ST
Heat 2
ND
Heat
Heat/Cool Y1,G Y1,Y2,G W1,G* W1,W2,G*
HeatPump(OneCompressor) Y1,G,O Y1,G,O Y1,G,B Y1,W2,G,B
HeatPump(TwoCompressors) Y1,G,O Y1,Y2,G,O Y1,G,B Y1,Y2,G,B
EmergencyHeat(HeatPumpOnly) N/A N/A W2,G N/A
1
ST
Cool 1
ST
Heat 2
ND
Heat
Heat/Cool Y1,G W1,G* W1,W2,G*
HeatPump(OneCompressor) Y1,G,O Y1,G,B Y1,G,B,W2
EmergencyHeat(HeatPumpOnly) N/A W2,G N/A
2010HR Output Chart
* Gnotonfor
gas/oilsystems
1010HR Output Chart
1
ST
Cool 1
ST
Heat
Heat/Cool Y1,G W1,G*
HeatPump(OneCompressor) Y1,G,O Y,G,B
* Gnotonfor
gas/oilsystems
(De)humidification Setting With Humidity Control Demand
No N/A
Humidication
Only
Heat W
Heat-Fan Wand/orG
Dehumidication
Only
Cool-No Gonly
Cool-Fan Yand/orG
Humidity Output Chart
Note:
When in dehumidication
mode and EAC is set to
Cool-2, Y2 will energize
to extend cooling cycle.
See Conguration menu
section 21, Page 17.
