Testing the Thermostat Humidity Control
Humidication Test –– when set to humidication, only
Totestthehumidier,setthemodeandfantothecorrectsetting:
HEAT-FAN:Eithertheheatingsystemorfanmustbeoperatinginorderforthehumidiertoturnon.
 HEAT:Heatmustbeoperatinginorderforthehumidiertoturnon.
 no:Noconditionotherthanhumidityreadingbelowsetpointanddifferentialwillturnonhumidier.
1.GotoMENU/HUMIDITYandpress
.
2.Changethehumiditysetpointabovetherelativehumiditybythedifferential(CongurationMenu,Section19,Page16).
3.Press
twice.YoushouldhearaclickandwhenyougobackintothehumiditysettingsyouwillseeONinthetopleft
cornerofthescreen.
4.Changethehumiditysettingbelowtherelativehumiditybythedifferential.Thehumidierwillturnoff.
Dehumidication Test –– when set to dehumidication, only
Totestdehumidication,setthemodeandfantothecorrectsettings.
COOL-FAN:Eitherthecoolingsystemorfanmustbeoperatinginorderforthedehumidiertoturnon.
 COOL-no:Thecoolingsystemmustbeturnedoffinorderforthedehumidiertoturnon.
 no:Noconditionotherthanhumidityreadingabovesetpointanddifferentialwillturnondehumidier.
1.GotoMENU/HUMIDITYandpress
.
2.Changethehumiditysetpointbelowtherelativehumiditybythedifferential(CongurationMenu,Section19,Page16).
3.Press
twice.Iftherelaycongurationissettonormallyopen,therewillbeaclickandthehumidityscreenwilldisplay
ON.Iftherelaycongurationissettonormallyclosed,thehumidityscreenwillnotdisplayON.
4.Changethehumiditysettingtogreaterthantherelativehumiditybythedifferentialbypressingthe .
5.Press
twice.Iftherelaycongurationissettonormallyclosed,therewillbeaclickandONisdisplayedonthehumidity
screen.Iftherelaycongurationissettonormallyopen,thehumidityscreenwillnotdisplayON.
