ICM Controls I3 1010HR - Configuration Settings: Temperature and Differential; Temperature Scale Selection; Stage Differential Settings; Staged Off Outputs Configuration

12
3. 2ndStageTemperatureDifferential(1°Fto5°F)(0.5°Cto2.5°C)
 Note:Not for 1010
Setthenumberofdegreesbetweenwhenstage1turnsonandwhenstage2turnson.
Pressthe
or tosetdifferentialvalue.Press toadvancetothenextscreen.
CONFIG
4.StagedOffOutputs
Selectwhethertheoutputsforheatingandcoolingarestagedoffindependentlyorare
satisedsimultaneously.

=Outputsoffsimultaneously. =Outputsstagedoffindependently.
Pressthe
or toset.Press toadvancetothenextscreen.
CONFIG
2.1stStageTemperatureDifferential(1°Fto5°F)(0.5°Cto2.5°C)
Setthenumberofdegreesbetweenyour“setpoint”temperatureandyour“turnon”temperature.
Pressthe
or tosetdifferentialvalue.Press toadvancetothenextscreen.
CONFIG
Configuration Mode Settings
ThesetupscreensforCongurationModeareasfollows:
1.TemperatureScale(ForC)
ChooseFahrenheitorCelsius.
Pressthe
or toselect.
Press
toadvancetothenextscreen.
CONFIG
