ICM Controls I3 1010HR User Manual

3
Important Safety Information
WARNING! : Alwaysturnoffpoweratthemainpowersupplybeforeinstalling,cleaning,orremovingthermostat.
• Thisthermostatisfor24VACapplicationsonly;donotuseonvoltagesover30VAC.
• Donotshortacrossterminalsofgasvalveorsystemcontroltotestoperation;thiswilldamageyourthermostatandvoidyour
warranty.
• Allwiringmustconformtolocalandnationalelectricalandbuildingcodes.
• Donotuseairconditioningwhentheoutdoortemperatureisbelow50degrees;thiscandamageyourA/Csystemandcause
personalinjuries.
• Usethisthermostatonlyasdescribedinthismanual.
To Remove Existing Thermostat
ELECTRICALSHOCKHAZARD –Turnoffpoweratthemainservicepanelbyremovingthefuseorswitching
theappropriatecircuitbreakertoOFFpositionbeforeremovingtheexistingthermostat.
1. Turnoffpowertoheating&coolingsystembyremovingthefuseorswitchingtheappropriatecircuitbreakeroff.
2. Removecoverofoldthermostat;thisshouldexposethewires.
3. Labeltheexistingwireswiththeenclosedwirelabelsbeforeremovingwires.
4. Afterlabelingwires,removewiresfromwireterminals.
5. Removeexistingthermostatbasefromwall.
6. Refertothefollowingsectionforinstructionsonhowtoinstallthisthermostat.
Battery Installation and Information
Two“AA”alkalinebatteriesareusedtopowerthethermostat.Theyareinstalledintothebackofthethermostat.
Orienttheminthecorrectdirectionasshownontheplasticthermostatcase.
Thebatteriesshouldbechangedyearlytopreventleakagefromdamagingthethermostatandvoidingyour
warranty.
Ifthebatteriesarenotchangedthethermostatwilleventuallydisplay
andconserveenergybymaintaininga
lowersetpointinheatingandahighersetpointincooling.

ICM Controls I3 1010HR Specifications

General

Brand	ICM Controls
Model	I3 1010HR
Category	Thermostat
Language	English
