20
SimpleComfort
®
2201
W2 L C Y2EGBOY1R
SimpleComfort
®
2201 Electronic Thermostat Conversion to:
Lennox HP19 and HP20 Heat Pump Systems
Lennox HP19 and HP20
Low Voltage Terminal Board
V-VR
M
R
F
E
Y
X
24VAC,Return
CompressorContactor
ReversingValve(CoolingMode)
FanContactorCircuit
EmergencyHeatingCircuit
2ndStageHeatingCircuit
24VAC,Common
