OTHER FUNCTIONS
8
■ RX frequency setting (for RX channels only)
The receive frequency in the RX channels can be re-pro-
grammed within 450 to 520 MHz frequency range depending
on the setting.
D RX channel setting
The RX channels does not appear on the LCD (default;
“Inhibit” setting) and you cannot select it. So the RX channels
should be set to “Enable” before programming the RX fre-
quency.
q While pushing and holding
*
and
*
, turn power ON
to indicate all pre-programmed RX channels (including the
inhibited channels.)
w Select the desired channel with [CH Up] or [CH Down],
then push
*
to set the displayed channel “Enable.”
e Turn the power OFF, then ON.
• The “Enable” channels appear on the LCD, and can be selected
with [CH Up]/[CH Down].
DRX frequency programming
q Select the desired RX channel (‘RX-XX’). (See at left)
w Push [Top]
(Function) to enter the function mode, then push
and hold [Top]
(RX VFO) for 2 sec. to enter the RX VFO
mode.
• Push
*
to toggle the bandwidth between wide or narrow.
e Push [CH Up] or [CH Down] several times to select the
desired frequency.
• The frequency changes according to the Wide/Narrow setting.
(p. 33)
*Regardless of the assigned key function.
