11
Bluetooth
®
OPERATION
11-17
Displays the paired Bluetooth
®
device
The maximum number of paired devices
Y
ou can pair two types of the Bluetooth
®
devices:
Headset and Data devices.
Up to 8 Bluetooth
®
devices can be paired with the
installed Bluetooth
®
unit.
Previous view
157
