7
NXDN™ OPERATION
7-11
Transmitting a call (Continued)
D Transmitting a Remote Monitor call
Remote Monitor call enables you to send a signal that
requires the target station to transmit the microphone
audio.
<Menu operation>
Portable: For the Ten-key and the Simple key types
Mobile: For the LCD types
(Menu > Signaling/Call > Call Menu)
1. Push [Menu] to display the Menu screen.
2. Push [Left] or [Right] to select “Signaling/Call,”
then
push [OK].
3. Push [Up] or [Down] to select “Call Menu,” then
push [OK].
4. Push [Up] or [Down] to select the Individual ID,
then push [OK].
5. Push [Up] or [Down] to select “Remote Monitor,”
then push [PTT] to transmit the Remote Monitor
call.
L “Success” is displayed after receiving an
acknowledgement from the target station.
L “Failed” is displayed if the target station does not
send back an acknowledgement.
6. The microphone audio can be heard for the preset
period of time.
D Transmitting a Radio Check
Radio Check call enables you to determine
whether the target station is turned ON, within the
communication range and on the channel, without
requiring any action from the target station user.
<Menu operation>
Portable: For the Ten-key and the Simple key types
Mobile: For the LCD types
(Menu > Signaling/Call > Call Menu)
1. Push [Menu] to display the Menu screen.
2. Push [Left] or [Right] to select “Signaling/Call,”
then
push [OK].
3. Push [Up] or [Down] to select “Call Menu,” then
push [OK].
4. Push [Up] or [Down] to select the Individual ID,
then push [OK].
5. Push [Up] or [Down] to select “Radio Check,” then
push [PTT] to transmit the Radio Check.
L “Success” is displayed after receiving an
acknowledgement from the target station.
L “Failed” is displayed if the target station does not
send back an acknowledgement.
To Next Page
