2
PANEL DESCRIPTION
2-19
Assignable Software key functions
Category: Signaling/Call (Continued)
Status
Push to display the “Status List” screen. Then, push
[Up] or [Down] to select a Status message.
After selecting, push [PTT] to send the message to
the currently selected station or group. Or, push [OK]
to set.
L See pages 7-6, 8-14 for details.
Message
While in the Standby mode, push to display the
“Message List” screen. Then, push [Up] or [Down] to
select a message.
After selecting, push [PTT] to send the message to
the currently selected station or group.
L See pages 7-8, 8-16 for details.
Write Message
In the Digital mode
Push to display the “Write Message” screen.
After entering, push [PTT] to send the message to the
currently selected station or group.
L See page 7-9 for details.
Category: Trunking
Site Select
In the Digital mode
Push to display the “Site Select” screen. Then, push
[Up] or [Down] to select a site number.
After selecting, push [OK] to set the selected site.
• The selected site is locked.
Site Lock
In the Digital mode
Push to turn the Site Lock function ON or OFF.
L When this function is turned ON, the transceiver cancels
resuming a roaming scan, and stays on the current site,
regardless of the error rate.
Roaming Request
In the Digital mode
Push to turn the Roaming Request function ON or
OFF.
L When this function is turned ON, the transceiver starts or
resumes a roaming scan, regardless of the error rate.
L When the Site Lock function is turned ON, pushing this
key resumes a roaming scan.
Category: Functions
Light
Push to turn ON the backlight for about 5 seconds,
even if the backlight setting is OFF.
Lock
Hold down for 1 second to turn the Key Lock function
ON or OFF.
L All assignable keys except the following are electronically
locked: [Monitor], [Light], [Lock], [Call], [Emergency], and
[Surveillance]. Also, [PTT] and [Power] are usable.
Sp. Func 1, Sp. Func 2, Sp. Func 3,
Sp. Func 4, Sp. Func 5, Sp. Func 6
Sp. Func 1 through Sp. Func 6 are reserved for PC
commands.
Public Address (For the Mobile type transceivers)
Push to activate the Public Address (PA) function.
And then, speak into the microphone while holding
down [PTT].
L When the PA function is activated, the audio output can
be separately controlled from the transceiver by pushing
[Up] or [Down].
NOTE: This function is usable when an external
unit, such as a audio amplier, speaker, and so on is
connected to the D-Sub 25 pin connector.
RX Speaker (For the Mobile type transceivers)
Push to turn the RX Speaker function ON or OFF.
L When the RX Speaker function is turned ON, the received
audio can be heard through an external speaker that is
connected to the D-Sub 25 pin connector.
NOTE:
• This function is usable when an external speaker is
connected to the D-Sub 25 pin connector.
• This function is useful when a user is out of the
vehicle.
• The audio output level is linked to the transceiver’s
volume control.
Hook Scan (For the Mobile type transceivers)
Push to temporarily turn the Hook Scan function ON
or OFF.
D For keys and keypads
To Next Page
