7
NXDN™ OPERATION
7-6
Transmitting a call
D Transmitting a Status message (Continued)
<Key operation>
Portable: For the Ten-key and the Simple key types
Mobile: For the LCD types
Using [Status]:
1. Push [Status] to display the “Status” screen.
2. Push [Up] or [Down] to select a Status Message,
then push [PTT] to transmit it.
L “Success” is displayed after receiving an
acknowledgement from the target station.
L “Failed” is displayed if the target station does not
send back an acknowledgement.
Portable: For All types
Mobile: For All types
Using [Status]:
Hold down [Status] for 1 second transmit the preset
Status Message.
TIP: This operation is enabled only when [Selector]’s
operation is set to “Status” using the programming
software.
NOTE: The status message can be automatically
transmitted when:
The transceiver is turned ON or OFF
L Set the Status message to be transmitted in ‘Power ON
Status’ or ‘Power OFF Status’ item, respectively.
L Set the target station ID in ‘Power Status ID,’ ‘Power
Status ID for Single-site Trunk’ or ‘Power Status ID for
Multi-site Trunk.’
After sending a voice message
LSet the ‘Send with Voice Call’ item to ‘Enable.’
L Set the Status message to be transmitted in ‘Send
Status Number item.
