PANEL DESCRIPTION
■ Function display
q RECEIVE MODE INDICATORS (p. 11)
Show the receive mode.
•AM, FM and WFM are available.
w DUPLEX INDICATORS (p. 22)
Appear when semi-duplex operation (repeater operation)
is in use.
•“–DUP” appears when minus duplex is selected; “DUP” only, ap-
pears when plus duplex is selected.
e TONE INDICATORS (pgs. 23, 26, 27)
➥“T” appears when the subaudible tone encoder is in use;
“TSQLë” appears during pocket beep operation and
“T SQL” appears when the tone squelch function is acti-
vated.
➥Only “ë” appears when the pocket beep function is in
use.
r RIT INDICATOR
Appears when the RIT (Receive Incremental Tuning) func-
tion for 800 MHz and above is in use. (p. 8)
t FREQUENCY READOUT
Shows the operating frequency, set mode contents, etc.
•The smaller “75,”“50” and “25” to the right of readout indicate 7.5,
5.0 and 2.5 kHz, respectively.
•The decimal point of the frequency flashes during scan.
y MEMORY CHANNEL READOUT
Shows the memory or call channel number, etc.
u MEMORY BANK INDICATOR
Flashes when the bank memory scan is activated.
i MEMORY MODE INDICATOR
Appears when a memory channel is selected.
