Icom IC-Q7A - Technical Specifications; General Specifications; Transmitter Specifications

36
13
SPECIFICATIONS
D General
•Frequency coverage : (unit: MHz)
U.S.A. Transmit 144–148, 440–450
Receive 30–823.995, 849–868.995,
894–1309.995*
Europe Transmit 144–146, 430–440
Receive 30–1309.995*
Italy Transmit 144–148, 430–440
Receive 30–1309.995*
Asia Transmit 144–148, 430–440
Receive 30–1309.995*
Australia Transmit 144–148, 430–440
Receive 30–1309.995*
U.S.A.-1 Transmit 144–148, 440–450
Receive 30–1309.995*
*Specifications guaranteed 30–1300 MHz.
•Mode : FM, AM*, WFM*
*Receive only.
•No. of memory channels : 200
•Usable temp. range : –10°C to +60°C;
+14°F to +140°F
•Tuning steps : 5, 6.25, 10, 12.5, 15, 20, 25,
30, 50 and 100 kHz
•Frequency stability : ±6 ppm (–10°C to +60°C)
•Power supply requirement : 2 AA(R6) Ni-Cd or alkaline
cells (negative ground)
•Current drain (VHF/UHF; at 3.0 V DC):
Tx max. power 440 mA/380 mA (typical)
Rx rated audio 170 mA (typical)
standby 95 mA (typical)
power saved 38 mA (typical)
•Antenna connector : SMA (50 Ω)
•Dimensions : 58(W)×86(H)×27(D) mm;
(projections not included) 2
9
⁄32(W)×3
3
⁄8(H)×1
1
⁄16(D) in
•Weight : 170 g; 6 oz
(w/antenna and battery)
•MIC/SP connector : 4-conductor 3.5 (d) mm (
1
⁄8˝);
2 kΩ/8 Ω
DTransmitter
•Modulation system : Variable reactance
•Output power : 350 mW typical (VHF)
(at 3.0 V DC) 300 mW typical (UHF)
•Spurious emissions :
Europe and Italy versions
Less than –60 dB (less than 1 GHz)
Less than –50 dB (greater than 1 GHz*)
Other versions
Less than –40 dB
*According to ETS 300 684 8.1.3 Limits: antenna port in
transmitter-active mode.
•Max. frequency deviation : ±5 kHz
