Icos MVS6000 - General Layout of the MVS6000 Family

Hardware
MVS6000 System Level Manual/1.0/Dec-2001 2-3
2.1.2 General Layout of the MVS6000 Family
This section shows the layout of the MVS6000 and the MVS6002 board.
Each board has different camera connectors, see page 2-12.
MVS6000
Activity LED
connectors
for analog
cameras
1
2
2 analog inputs
DSP activity LEDs
DSP
DSP
IO
CTRL
input
FIFOs
CTRL CTRL
32 MB
PCI
CTRL
camera
CTRL
flash/trigger LI2 LI1 PIO
test
connector for
camera module
connector for
camera module
input 1 LED
input 2 LED
