MVS6000
3-24
MVS6000 System Level Manual/1.0/Dec-2001
3.3.2.3 Camera Numbering
The numbering of the cameras on the MVS6000 board is as follows:
· the SR cameras are camera 1, camera 2, camera 3 and camera 4:
cam 1 cam 2 cam 3 cam 4
connector 1
XX
connector 2
XX
Connector 1:
· if there is only one camera, it is camera 1
· if two cameras are connected (by using a breakout box), camera 1 is connected above
camera 2 (see page 2-11).
Note: this is the opposite of the MVS3x0 board where camera 2 was connected
above camera 1.
Connector 2:
· if there is only one camera, it is camera 3
· if two cameras are connected (by using a breakout box), camera 3 is connected above
camera 4 (see page 2-11)
Note: this is the opposite of the MVS3x0 board where camera 4 was connected
above camera 3.
· the HR cameras are camera 1 and camera 3:
cam 1 cam 3
connector 1 X
connector 2 X
