MVS6000
2-14
MVS6000 System Level Manual/1.0/Dec-2001
An overview of the available breakout boxes:
MVS number connector In connectors out Connectors out: pin layout color
MVS962 SubD15 3 x Hirose Old pin layout gray
MVS963 SubD15 2 x Hirose old pin layout gray
MVS964 SubD15 2 x Hirose new EIAJ pin layout blue
MVS966 SubD15 3 x Hirose new EIAJ pin layout blue
Cables
there are three types of cables to connect the camera with the MVS6000 board:
· SR cables to connect with the standard Hirose connector
· SR cables to connect with the new EIAJ standard Hirose connector (blue label)
· HR cables
Note: For the SR cameras, the same cables are used as for connecting to the MVS3x0.
For the HR cameras (ADIMEC), other cables are used than for connecting to the MVS3x0.
The next two tables give an overview of the cables that must be used with and without a video
splitter.
Note: A video splitter transmits the output of the two cameras to the two “twin” MVS boards.
Camera connections without video splitter:
camera type
connection
HR camera
SR camera
old standard
SR camera
EIAJ standard
blue label
camera to
MVS3x0
SL:
CI:
CW4448 (2m)
CW4449 (5m)
CW4450 (10m)
CW4332 (3m)
camera to
MVS6000
SL:
CI:
CW4703 (2m)
CW4704 (5m)
CW4705 (10m)
CW4642 (3m)
SL:
CI:
CW4473 (2m)
CW4474 (5m)
CW4475 (10m)
CW4603 (5.5m)
CW4711 (2m)
CW4712 (5m)
CW4713 (10m)
camera to
breakout box
- - -
CW4430 (2m)
CW4431 (5m)
CW4432 (10m)
