MVS6000
A-4
MVS6000 System Level Manual/1.0/Dec-2001
Debug
00C3 get error log
007F set write functions
0010 upload error log entry
00F0 time trace settings
Info
0300 get configuration parameters
Communication
00AC input transparent communication
Boot
03F8 Boot MVS340 from Application SW
0BF8 Boot MVS340 from Boot SW
0BF5 clear flash
0BF6 load flash
0BF7 set flash start address
0BFD load&program flash disc
Input
0003 autogain calibration
Messages with Incompatibilities
General remarks
SIP profile is not supported anymore and is mapped on the RIP profile type
NIP profile is mapped to a new profile type called SNIP.
Info
00DD set setup parameters: most cases not supported anymore, still supported
are: 15, 16, 17, 115
00DE get setup parameters: most cases not supported anymore, still supported
are: 1, 15, 16
009E get package info: p11-p14 reply will be 0 (camera size, display size)
Processing
00B0 1D data processing
case 2, cp9, value 3 and 4 minimum profile and maximum profile not supported in
phase1, will return error
00B2 2D data processing
case 2, cp10, value 1 and 2 minimum mosaic and maximum mosaic not supported in
phase1, will return error.
0096 get mosaic
p17, value 1 and 2 minimum mosaic and maximum mosaic not supported in phase1,
will return error
