User’s
All Licenced & Registered Engineers carry an ID card, and have a registration number. Both should be recorded in the
Commissioning Checklist.
1. INTRODUCTION
The Logic + System S is a system boiler, featuring full sequence
automatic spark ignition and fan assisted combustion. It is
designed to provide central heating and hot water when a separate
hot water cylinder is installed.
Due to the high efciency of the boiler, condensate is produced from
the ue gases and this is drained to a suitable disposal point through
a plastic waste pipe at the base of the boiler. A condensate ‘plume’
will also be visible at the ue terminal.
SAFETY
Current Gas Safety (Installation & Use) Regulations or
rules in force.
In your own interest, and that of safety, it is the law that this
boiler must be installed by a Licensed & Registered Engineer, in
accordance with local and national laws and regulations.
It is essential that the instructions in this booklet are strictly
followed, for safe and economical operation of the boiler.
ELECTRICITY SUPPLY
This appliance must be earthed.
Supply: 230 V ~ 50 Hz. The fusing should be 3A.
IMPORTANT NOTES
• This appliance must not be operated without the casing
correctly tted and forming an adequate seal.
• If the boiler is installed in a compartment then the compartment
MUST NOT be used for storage purposes.
•
If it is known or suspected that a fault exists on the boiler then
it MUST NOT BE USED until the fault has been corrected by a
Licensed & Registered Engineer.
• Under NO circumstances should any of the sealed components
on this appliance be used incorrectly or tampered with.
•
This appliance can be used by children 8 years and
above. Also persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
provided they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
CONTENTS
1. Introduction .............................................................. 2
Safety ......................................................................... 2
Electricity Supply ........................................................ 2
Important Notes .......................................................... 2
2. Boiler Operation ....................................................... 3
Controls Diagram........................................................ 3
To Start the Boiler ....................................................... 3
Control of Water Temperature .................................... 3
Efcient Heating System Operation............................ 3
Weather Compensation .............................................. 3
Boiler Frost Protection ................................................ 3
Boiler Restart .............................................................. 3
Mains Power Off ......................................................... 3
3. Condensate Drain ..................................................... 4
4. Loss of System Water Pressure .............................. 4
5. General Information ................................................. 4
Boiler Pump ................................................................ 4
Minimum Clearances .................................................. 4
Escape of Gas ............................................................ 4
Cleaning ..................................................................... 4
Maintenance ............................................................... 4
6. Points for the Boiler User ........................................ 5
Troubleshooting .......................................................... 5
7. Normal Operation Display Codes ........................... 6
8. Fault Codes ............................................................... 7
